The BXP-100 is a compact, reliable 4K media player built for straightforward digital signage deployments. Designed as a solid, no-fuss solution, it delivers smooth 4K playback at 60fps in an ultra-compact, fanless form factor—ideal for environments where space, noise, and stability matter.
Running on Android 12, the BXP-100 gives you the flexibility to choose your preferred CMS, so you’re not locked into a single ecosystem. While it doesn’t include a built-in content management system, it comes ready with Qbic’s Remote Configuration Centre (RCC), allowing you to quickly connect, configure, and manage devices remotely—accelerating rollouts and simplifying ongoing control.
The fanless solid-state design improves durability and longevity, while the built-in watchdog ensures automatic recovery and reliable uptime—perfect for unattended, always-on installations.
With dual-band Wi-Fi and a compact footprint (127 x 66 x 18.5 mm), the BXP-100 is easy to install behind screens or in tight spaces, making it a practical choice for retail, corporate, and hospitality environments.
Key Features:
- 4K Ultra HD playback at 60fps
- Android 12 OS for flexible CMS compatibility
- RCC (Remote Configuration Centre) for fast deployment and remote management
- Fanless, solid-state design for silent and reliable operation
- Built-in watchdog for system stability and auto-recovery
- Dual-band Wi-Fi connectivity
- Ultra-compact size: 127 x 66 x 18.5 mm
- 2-year warranty for peace of mind
A dependable, deployment-ready media player that gives you control without complexity.
- 4K Ultra HD output at 60fps via HDMI with CEC
- 4K upscaling, enhances lower-resolution content to near-4K quality
- Dual Watchdog: CPU watchdog + independent hardware watchdog, automatic recovery from any fault
- Fanless, silent design, no moving parts for reliable 24/7 commercial operation
- Ultra-compact: 127 x 66 x 18.5mm, 40% smaller, 50% thinner than comparable players
- IEEE 802.1X authentication on both Wi-Fi and Ethernet
- SSL/TLS secured data connection and administrative password protection
- Scheduled power on/off and real-time clock (RTC)
- APK / Content URL auto launch and Kiosk mode
- Remote Configuration Center (RCC): manage all Qbic devices via web browser, individually or in batch
- Remote firmware and APK updates over the air (OTA)
- Bluetooth Beacon transmitter mode
- Dual-band Wi-Fi 5GHz/2.4GHz (802.11 a/b/g/n/ac) and Ethernet
- VESA 75/75mm mount kit and Velcro mount included
| Specification | Detail |
|---|---|
| OS | Android 10 |
| CPU | ARM Quad-core Cortex-A53, 1.5GHz |
| GPU | Mali-G45 MP2 |
| Memory | 2GB DDR4 |
| Storage | 32GB |
| Watchdog | Dual (CPU + Independent) |
| Display Output | 1 x HDMI (4K 3840x2160@60fps) |
| HDMI CEC | Yes |
| Video Playback | H.264 4K@60p, H.265 4K@60p, MPEG-1/2/4, VC-1, AVS, AVS+ |
| Ethernet | 1 x RJ45 (10/100 BASE-T) |
| WLAN | 802.11 a/b/g/n/ac (dual-band 2.4GHz / 5GHz) |
| USB | 1 x USB 2.0 Type-A, 1 x USB 3.0 Type-A |
| ADB | 1 x Micro USB |
| Storage Expansion | 1 x Micro SDXC slot (max. 2TB) |
| Power | DC 5V/2A |
| Bluetooth Beacon | Yes (transmitter mode) |
| Dimensions (WxDxH) | 127 x 66 x 18.5mm |
| Mounting | VESA 75/75mm (included), Velcro mount (included) |
| Operating Temp | 0°C to 60°C |
| Storage Temp | -20°C to 70°C |
| SKU | Model |
|---|---|
| BXP-100 | Phantom Ultra Compact 4K Digital Signage Player |
| Detail | Value |
|---|---|
| Includes | 5V power supply, Velcro tie, 75mm VESA mounting kit |
| Optional | USB Wi-Fi dongle for wireless connectivity |
Compatibility
- 1 x HDMI output (4K@60fps)
- HDMI CEC supported
- Wired LAN/PoE via RJ45
- wireless via USB Wi-Fi dongle (802.11 a/b/g/n/ac)
- VESA 75/75mm wall or display mount (included)
- Velcro mount (included)
- Retail digital signage and promotional displays
- corporate lobby and internal communications
- hospitality and hotel information displays
- education and healthcare digital notice boards
- always-on public displays requiring 24/7 reliability
