By Qbic

Luminen 10.1" - Smart Control with Touch Screen, Gateway and Mini Server

$1,635.00
$1,635.00
SKU: HC-1070N
Availability: Contact to order

Back orders delivered in 4 weeks

Not available for local pickup. On backorder

Free standard shipping on all orders over $250

Overview

The Qbic Luminen 10 is a 10.1" three-in-one luxury smart control delivering a full FHD 1920 x 1200 IPS touch display, NFC, 5MP camera, and PoE 802.3af/at in a premium wall panel for enterprise and commercial smart building deployments. Android 13, Linux, and Yocto BSP provide broad OS flexibility, while Wi-Fi 6, Gigabit Ethernet with TSN, and RS485 cover all connectivity requirements. Protected by Qbic Fortify+ security and centrally managed via the Remote Configuration Center.

Key features
  • Three-in-one design: touch screen, IoT gateway, and server in a single device
  • 10.1" FHD IPS touch display, 1920 x 1200 resolution, 0-300 nits adjustable brightness
  • NFC (13.56MHz) for contactless interaction and access control
  • 5MP fixed-focus front camera
  • Android 13 / Linux / Yocto BSP, flexible OS options for enterprise deployments
  • Neural Processing Unit (NPU) 2.3 TOPS for AI-accelerated applications
  • Gigabit Ethernet with Time Sensitive Networking (TSN)
  • PoE 802.3af/at compliant, single cable power and network
  • Wi-Fi 6 (802.11 a/b/g/n/ac/ax) and Bluetooth 5.0
  • Dual microphones and ambient light / proximity sensors
  • Qbic Fortify+ security: Access Protection, Data Protection, Environment Protection
  • Remote Configuration Center (RCC): manage all Qbic devices via web browser, individually or in batch
  • Custom app deployment: install APK files via USB, contact Leading Solutions for compatible APK files
  • Quick Development Kit (QDK) for faster custom app development
  • Regular Android OS security patching and long-term component support
  • One-gang, tabletop, surface, and glass mounting options

Warranty

2-year warranty, extendable to 5 years

Certifications
  • ISO/IEC 27001:2022, Information Security Management (Certificate TW25/00000583, valid to 9 July 2028)
Product specs Download
Assembly guide Download
Luminen 10.1-inch smart control panel with touch screen, gateway, and mini server
$1,635.00
$1,635.00

Technical details

The Luminen 10.1″ smart panel offers a compact yet powerful interface for automation, access control, and smart room environments. It integrates a responsive touchscreen, edge computing gateway, and Android 15 mini-server into one robust device. With advanced connectivity, antimicrobial design, and PoE+ support, it’s perfectly suited for high-use public spaces or professional AV projects. It runs on Android 15 with remote OTA updates, ensuring long-term performance and compatibility.

Key Features:

  • 10.1″ touchscreen with 1920 × 1200 resolution (16:10)

  • Anti-microbial Corning® Gorilla® Glass surface

  • Android 15 with remote OTA updates

  • Wi-Fi 6 and Bluetooth 5.0 wireless support

  • Onboard 2.3 TOPS NPU for AI integration

  • Gigabit RJ-45 (PoE+), RS-485, CAN Bus, USB OTG

  • Integrated 5 MP camera, dual speakers, and microphone

  • True-color LED status indicators

  • Ambient light sensor for automatic brightness adjustment

  • Compatible with standard wall boxes for easy install

  • Warranty: Two-year standard warranty.

  • Optional Mullion Mount and Recess Wall Mount available separately.

  • Three-in-one design: touch screen, IoT gateway, and server in a single device
  • 10.1" FHD IPS touch display, 1920 x 1200 resolution, 0-300 nits adjustable brightness
  • NFC (13.56MHz) for contactless interaction and access control
  • 5MP fixed-focus front camera
  • Android 13 / Linux / Yocto BSP, flexible OS options for enterprise deployments
  • Neural Processing Unit (NPU) 2.3 TOPS for AI-accelerated applications
  • Gigabit Ethernet with Time Sensitive Networking (TSN)
  • PoE 802.3af/at compliant, single cable power and network
  • Wi-Fi 6 (802.11 a/b/g/n/ac/ax) and Bluetooth 5.0
  • Dual microphones and ambient light / proximity sensors
  • Qbic Fortify+ security: Access Protection, Data Protection, Environment Protection
  • Remote Configuration Center (RCC): manage all Qbic devices via web browser, individually or in batch
  • Custom app deployment: install APK files via USB, contact Leading Solutions for compatible APK files
  • Quick Development Kit (QDK) for faster custom app development
  • Regular Android OS security patching and long-term component support
  • One-gang, tabletop, surface, and glass mounting options
SpecificationDetail
ModelLuminen 10
Display Size10.1" IPS
Resolution1920 x 1200
Brightness0-300 nits
OSAndroid 13 / Linux / Yocto BSP
CPUARM Quad-core Cortex-A53 up to 1.8GHz (64-bit)
NPU2.3 TOPS
Memory4GB LPDDR4
Storage32GB eMMC
NFC13.56MHz
TouchYes, multi-touch
Camera1 x 5MP Fixed focus
MicrophoneDual
SensorAmbient light, Proximity
Bluetooth Beacon (BLE)Yes
PoE802.3af/at
Ethernet1 x RJ45 Gigabit with TSN
WLAN802.11 a/b/g/n/ac/ax (Wi-Fi 6)
BluetoothBT 5.0
USB1 x USB 3.0 Type A / 1 x USB Type-C (ADB)
Speaker1W x 2
Dimensions (WxHxD)241.9 x 173.4 x 20.8mm
MountingOne-gang, Tabletop, Surface mount, Glass mount
HousingPlastic & Aluminium Alloy
Operating Temp0°C to 40°C
Storage Temp-20°C to 60°C
SKUModel
Luminen 1010.1" Smart Control Panel
DetailValue
OS optionsAndroid 13, Linux, Yocto BSP
NFC13.56MHz
MountingOne-gang, Tabletop, Surface mount, Glass mount

Compatibility

NFC
  • 13.56MHz
Mounting
  • One-gang wall mount
  • Tabletop
  • Surface mount
  • Glass mount
Suitable for
  • Smart building and home automation control
  • meeting room and space management
  • AV and lighting control
  • hospitality and hotel room controls
  • corporate and residential premium installations

Features

  • A Greener Smart Control

    Equipped with sensors, this device boasts an intelligent system that automatically adjusts its brightness according to the surrounding environment, conserving energy and prolonging battery life. As well as being powered by a low power ARM-processor.

  • Connectivity Without Limits

    Experience limitless integration, featuring a diverse array of IO ports and cutting-edge wireless connectivity with WiFi 6 and Bluetooth 5. Connect to a physical ecosystem or go wireless.

  • The Ultimate 3-in-1 Convenience

    Boasting a trifecta of functionality including a touch screen, gateway connectivity, and mini-server capabilities. This innovative combination offers a convenient solution for developers and integrators seeking to streamline their projects.

  • AI-Driven Convenience & Security

    Impressive AI processing power of 2.3 TOPS. This advanced feature expands the capabilities of your device, enabling a range of AI-powered functions such as user identification, authentication, and safety features.
