By Magewell

Ultra Encode AIO - Universal encoder

$1,747.67
$1,747.67
SKU: MG-531300000
Availability: In stock with supplier

Overview

The Magewell Ultra Encode AIO is a standalone, single-channel universal encoder that accepts HDMI (up to 4Kp60) and 3G/6G-SDI (up to 4Kp30) inputs simultaneously, and can encode either source alone or mix both into a combined picture-in-picture or side-by-side output. It performs dual-stream H.264/HEVC encoding with up to eight simultaneous audio streams, and streams over RTMP(S), SRT, RTSP, NDI|HX2/HX3, HLS and MPEG-TS, while also supporting local recording to SD card, USB storage or network storage.

Key features
  • Dual HDMI and SDI Input: Accepts HDMI up to 4Kp60 and SDI up to 4Kp30 simultaneously.
  • Advanced Compression: Encodes H.264 and HEVC (H.265) with dual-stream output up to 32 Mbps.
  • Extensive Protocols: Streams via RTMP(S), SRT, RTSP, NDI®|HX2/HX3, HLS and more, up to 6 sessions.
  • Simultaneous Recording: Records to SD card or USB storage with scheduled and loop recording.
  • Platform Ready: Native YouTube, Twitch and Facebook support over wired or wireless network.

Warranty

2-year warranty

Magewell Stream (Encoding) Ultra Encode AIO - Universal encoder
$1,747.67
$1,747.67

Technical details

The Magewell Ultra Encode AIO is a standalone universal encoder that accepts HDMI and SDI at the same time and can combine them into one stream. It is engineered for live streaming, recording and AV-over-IP production without a computer.

Perfect for events, worship and corporate streaming, the Ultra Encode AIO delivers professional multi-input encoding in a standalone device.

  • Dual HDMI and SDI Input: Accepts HDMI up to 4Kp60 and SDI up to 4Kp30 simultaneously.
  • Advanced Compression: Encodes H.264 and HEVC (H.265) with dual-stream output up to 32 Mbps.
  • Extensive Protocols: Streams via RTMP(S), SRT, RTSP, NDI®|HX2/HX3, HLS and more, up to 6 sessions.
  • Simultaneous Recording: Records to SD card or USB storage with scheduled and loop recording.
  • Platform Ready: Native YouTube, Twitch and Facebook support over wired or wireless network.

Frequently Asked Questions

What inputs does the Ultra Encode AIO accept?

It accepts HDMI up to 4Kp60 and SDI up to 4Kp30 at the same time, and can combine them into one stream.

Which codecs does it support?

It encodes H.264 and HEVC (H.265) with dual-stream output up to 32 Mbps.

Which streaming protocols are supported?

It streams via RTMP(S), SRT, RTSP, NDI|HX2/HX3, HLS and more, with up to 6 sessions.

Can it record?

Yes. It records to an SD card or USB storage, with scheduled and loop recording.

Can it stream directly to YouTube?

Yes. It has native YouTube, Twitch and Facebook support over wired or wireless networks.

Does it need a computer?

No. It is a standalone encoder that streams and records without a computer, over wired or wireless networks.
